Zehnder’s retrofit MVHR systems are now available in the UK.
As such they lend themselves ideally for retrofitting MVHR systems.
Key parameters:
– Balanced single room MVHR (PH certified)
– 15 – 50 m3/h (4.2 – 13.9 l/s) output
– One 340mm core through external wall needed
– For 335 to 900mm thick walls
– ERV core (heat & humidity recovery)
– Humidity, CO2 and VOC control possible
– Quiet operation
The ComfoSpot 50 can switch between 4 fan speed settings::
| Fan speed | Volume flow | Volume flow | Thermal efficiency | Humidity recovery | Power cons. | Noise level |
| [m³/h] | [l/s] | [%] | [%] | [W] | [dB(A)] | |
| 1 | 15 | 4.2 | 85 | 74 | 4 | 5.2 |
| 2 | 25 | 6.9 | 76 | 58 | 6 | 14.7 |
| 3 | 40 | 11.1 | 69 | 46 | 10 | 23.2 |
| 4 | 50 | 13.9 | 62 | 44 | 15 | 29 |
Key features:
– Can be connected with one 90mm supply duct and one 90mm extract duct to connect one additional supply and extract room.
– 15 – 60 m3/h (4.2 – 16.7 l/s) output
– One 270mm core through external wall needed
– For 275 to 900mm thick walls
– ERV core (heat & humidity recovery)
– Humidity, CO2 and VOC control possible
– Quiet operation – even quieter with supply ducting and extract ducting
The ComfoAir 70 can switch between 4 fan speed settings:
| Fan speed | Volume flow | Volume flow | Thermal efficiency | Humidity recovery | Power cons. | Noise level no ducting |
Noise level 1 duct |
Noise level 2 ducts |
| [m³/h] | [l/s] | [%] | [%] | [W] | [dB(A)] | [dB(A)] | [dB(A)] | |
| 1 | 15 | 4.2 | 90 | 84 | 4 | 11.0 | 9.2 | 2.9 |
| 2 | 25 | 6.9 | 83 | 73 | 5 | 23.6 | 16.3 | 16.0 |
| 3 | 40 | 11.1 | 76 | 61 | 9 | 29.4 | 24.3 | 16.2 |
| 4 | 60 | 13.9 | 71 | 54 | 17 | 36.4 | 31.2 | 22.7 |
